Core Material | LiFePO4 |
Rated Voltage | 48V / 51.2V |
Series Parallel Mode (S series, P parallel) | 16S1P |
Rated Capacity | 100Ah@0.2C |
Rated Power | 5120Wh |
Internal Resistance | ≤30mΩ |
Communication | RS485/RS232/CAN |
Display | LCD |
Cycle Life | 3000 times @ 25℃ |
Application | Hospital, bank data center, wall-mounted home, enterprise energy storage backup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply |
Charging Mode (CC/CV) | CC/CP/VP |
Charging Current | 0.2C (Standard) |
Charge Cut Off Voltage | 58.4V/CELL |
Max Charge Current | Max0.5C @25℃ |
Discharge Cut Off Voltage | 44.8V |
Discharge Mode | CC/CP/VP |
Discharge Current | 0.5C@25℃ |
Max Discharge Current | Max1C @25℃ |
Charge Working Temperature Range | 0~+50℃ |
Discharge Working Temperature Range | -20 +55℃ |
Storage Environment | 25±5℃ |
Water Dust Resistance | IP55 |
Net Weight | 44.5KGS |
Dimension (L*W*H) mm | 555*390*150 |
